OPSS II



SENSOR & TRANSMITTER SPECIFICATIONS NOTE
Pressure monitoring range :
 0~76 psi
Temperature monitoring range :
 -40°F to 257°F
Pressure reading accuracy :
 ±1 psi (in typical environment)
Temperature reading accuracy :
 ±4°F (in typical environment)
Battery :
 3.6V
Operating frequency :
 433.92 MHz
Storage temperature :
 -40°F to 250°F
Operating temperature :
 -22°F to 248°F
Operating humidity :
 95%
Transmission power : 5dBm max

OE Sensors will continue to transmit a signal after being removed from the tire. Prevent mixing signals by completely removing the OE sensor from the service area

If a vehicle has been in an accident requiring a new ECU, the original sensor application needs to be used for the vehicle to recognize the sensors
